Fuel supply system: Direct injection: Common Rail
Ignition: Compressed ignition
Atmospheric/Supercharged: Turbo Charged
Fuel type: DIESEL
Oil capacity in initial fill (I): 5.0
Alternator (A): 110-140
Battery (Ah/A): 70 / 420
Acceleration 0-80 km/h (s): 7.5
Acceleration 80-120 km/h (s) at V: 15.8
Acceleration 1000 m (s): 32.8
Type: 5D
Wheelbase (mm): 2,630
In running order with driver (kg): 1,382
In running order with driver (kg) Front / Rear: 822 / 560
Maximum weight allowed (kg): 1,950
Maximum weight without brake (kg): 690
Maximum weight w/brake 8% (kg): -
Maximum weight w/brake 12% (kg): -
Gearbox type: MQ250-5F
Ratios I: 3.778
II: 1.944
III: 1.185
IV: 0.816
V: 0.625
VI: -
VII: -
R: 3.600
Group 1 ratio: 3.647
Group 2 ratio: -
Group 3 ratio: -
Speed 1000 rpm in IV/V (km/h): 39.9 / 52.1 /--/--
Rims: 7JX17"
7.5JX18"
Tyres: 205/55 R17 95 XL V
225/45 R18 95 XL W
Front suspension: Independent type McPherson - coil springs - hydraulic shock absorber
Rear suspension: Semirigid axle, coil springs and hydrolic shock absorbers
Steering System: Rack Electric Power System (R-EPS)
Turning diameter (m): 10.2
Brake system: Dual hydraulic circuit and brake system diagonal split with brake booster
Type front and rear brakes: Front ventilated disc brakes and rear solid disc brakes
Front brakes (mm): 288x25
Rear brakes (mm): 272x10
Direct injection: Common Rail
Compressed ignition
Turbocharged
DIESEL
5.0
110-140
70/420
